Reinforced double wall construction with 1-1/2 in (3.8 cm) air space on sides, top, bottom, back and doors
Constructed of 18-gauge steel
Lead-free, high-gloss, baked-on powder finish
Continuous piano hinges
Ground connection
Four adjustable galvanized leveling legs
Trilingual warning labels
2 in (5.1 cm) raised leakproof sill
Patented adjustable galvanized steel shelves direct spills to back and bottom of leakproof sump and hold 350 lbs. (158.8 kg) Uniform Distributed Load (UDL)
Internal and external welded construction
Two 2 in (5.1 cm) internal vents with fire baffle and cap
Flush mounted door handle with key lock
Three-point stainless steel bullet latching system
3 in (7.6 cm) centers for shelf brackets
Self-latching doors
Door closings: Self-Closing (135° opening)
Concealed self-close mechanism provides obstruction-free access to top shelf space
Self-indexing doors guarantee they will close in sequence and ensure a tight closure from top to bottom
WARNING:This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Description
90 Gallon, self-closing, Flammable Liquid Safety Cabinet is constructed of 18-gauge (1 mm) steel. The sides, top, bottom, and doors are double-walled with a 1-1/2 in (3.8 cm) air space between walls. Includes two vents, each have 2 in (5.1 cm) threaded fittings and a fire baffle and cap. Cabinets have a high gloss powder coat finish with red trilingual warning, plus grounding attachment, 3-point latch system, and 2-in (5.1 cm) raised, leakproof door sill. Each shelf is adjustable on 3 in (7.6 cm) centers, supported by 4 brackets, with a 350 lbs (159 kg) safe allowable load. Cabinets are FM-Approved and meet NFPA Code 30 and OSHA requirements.
Specifications
More Information
Model No
9010XRED
Color
Red
Material Specifications
18-Gauge Steel
FM Approval
Yes
OSHA Compliance
Yes
Complies with NFPA Code 30
Yes
Door Style
Self-close
UPC
048441692118
Dimensions, Exterior
43W x 34Dx 65H
Dimensions, Interior
39.5" W x 30.34" D x 60.5" H (100.3 x 77.1 x 153.7 cm)
